Description PROFIBUS DP Modular expansion of an XM control Extended temperature range from -25 °C to +60 °C Protection type IP20 Product description With the extension modules, it is possible to extend an XM control with additional communication interfaces. The extension modules can be easily connected to the control side by side. Technical data General data Type XFE01.1-FB-10 XFE01.1-FB-11 Ambient temperature (operation) °C -25 ... +60 -25 ... +60 Permissible relative humidity (operation) 5 % ... 95 % acc. to DIN EN 61131-2 Protection type IP20 Weight g 120 120 Interfaces Type XFE01.1-FB-10 XFE01.1-FB-11 Fieldbus system PROFIBUS DP (master/slave) PROFIBUS DP (slave) Electrical data Type XFE01.1-FB-10 XFE01.1-FB-11 Supply voltage U V DC 24 24 Umin ... Umax 18 V ... 31.2 V (including all tolerances, including ripple) Residual ripple % 5 5 Mechanical tests Type XFE01.1-FB-10 XFE01.1-FB-11 Vibration resistance g 5 5 Shock g 30 30 Components Embedded Controls XM21 Embedded Controls XM21 CPU: Intel ATOM E620 600 MHz On-board Sercos master with 250 μs cycle time Gigabit Ethernet, USB host and device, SD card slot, diagnostic LED Modular expansion options with extension and I/O modules Ideal for centralized and decentralized controller topologies Scaled in the scope of performance and functions based on the latest chip technology Robust design with extended temperature range Simple, flexible I/O integration Optionally expandable with extension modules (communication, safety) Protection type IP20 Operating instructions Safety and Security Instructions Embedded Controls XM22 Embedded Controls XM22 CPU: Intel ATOM E660 1300 MHz On-board Sercos master with 250 μs cycle time Gigabit Ethernet, USB host and device, SD card slot, diagnostic LED Modular expansion options with extension and I/O modules Ideal for centralized and decentralized controller topologies Scaled in the scope of performance and functions based on the latest chip technology Robust design with extended temperature range Simple, flexible I/O integration Optionally expandable with extension modules (communication, safety) Protection type IP20 Operating instructions Safety and Security Instructions Certification Certification Dimensions Dimensions Type XFE01.1-FB-10 XFE01.1-FB-11 A mm 35 35 B mm 126.3 126.3 C mm 52 52 Certification Certificates Type XFE01.1-FB-10 XFE01.1-FB-11 Norms and Standards CE/UL/CSA Downloads IndraControl XFE 01.1 Extension Modules Profibus, RT-Ethernet, Sercos, CAN Manual | R911345570 | 2021-09-16 | English | PDF | 2.3MB Product Groups: XM Edition 06 IndraControl XFE 01.1 Erweiterungsmodule Profibus, RT-Ethernet, Sercos, CAN Manual | R911345569 | 2021-09-16 | German | PDF | 2.1MB Product Groups: XM Ausgabe 06 MKE Synchron-Servomotoren UL/CSA Manual | R911414372 | 2021-12-08 | German | PDF | 2.7MB Product Groups: MKE037, MKE047, MKE098, MKE118 Ausgabe 01 MKE Synchron-Servomotoren UL/CSA (Hiperface DSL-Geber) Manual | R911415429 | 2021-12-10 | German | PDF | 2.5MB Product
