Description For valves with round connector according to EN 175201-804, 11-pole + PE Technical data Short designation 12PN11REFS Design no code (see unit dimensions) Ambient temperature fixed installation °C -40 … +80 flexible °C -20 … +80 Protection class according to EN 60529 IP65 with mating connector mounted and fitted Number of poles 11 + PE Standard DIN 43651 Certification/conformity RoHS Derating - Connection line F-C-PURö-JZ, coolant-resistant, Cu shielded,increased oil resistance Wire cross-section 12 x 0,75 mm2 Shielding braid overlap 85 % Core marking PE green-yellow others black wires with serial white numbers Line diameter mm 10.5 Bending radius fixed installation min. 5 x line diameter flexible min. 10 x line diameter Short designation 12PN11REFF Design no code (see unit dimensions) Ambient temperature fixed installation °C -40 … +80 flexible °C -5 … +70 Protection class according to EN 60529 IP65 with mating connector mounted and fitted Number of poles 11 + PE Standard DIN 43651 Certification/conformity - Derating - Connection line Data line: PVC, Unitronic LiYCY, shielded, flame-resistant according to IEC 60332-1-2 Control line PVC, classic 110, flame-resistant according to IEC 60332-1-2 Wire cross-section Data line: 10 x 0,14 mm2 Control line 3 x 1,0 mm2 Core marking PE green-yellow others black wires with serial white numbers Line diameter Data line: mm 6.1 Control line mm 6 Bending radius fixed installation min. 6 x line diameter flexible min. 15 x line diameter (For applications outside these values, please consult us!) Symbols/Circuit diagrams 11-pole + PE, metal version, shielded 11-pole + PE, plastic version, shielded Dimensions 12PN11REFS Dimensions in mm 12PN11REFF Dimensions in mm 1, 2 Line fitting, tightening torque MA = 1 … 1.5 Nm Downloads Leitungsdosen und Kabelsätze für Ventile und Sensoren in der Hydraulik Data Sheet | RD08006 | 2021-05-01 | German | PDF | 1.4MB Product Groups: Mating connectors and cable sets Mating connectors and cable sets for valves and sensors in hydraulics Data Sheet | RE08006 | 2021-05-01 | English | PDF | 1.5MB Product Groups: Mating connectors and cable sets
