Single ended Крутящий момент arms Hägglunds TCA

Описание Valid for: Hägglunds motors CA, CB, CBP and CBM Особенности Easy mounting i.e. No alignment problems, couplings and bed plates are eliminated. Fast mounting of motor to driven shaft. Robust torque-transmitting. Controlled external forces on driven shaft. Space saving. i.e. close mounting to the driven machine. Take up radial and axial movements on driven shaft. Electrical isolated option to avoid current from passing through the hydraulic motor. Описание продукта If the driven machine can stand the forces generated by the Hägglunds single ended torque arm arrangement, the Hägglunds single ended torque arm is an easy and favorable mounting solution for the Hägglunds hydraulic motor. The torque arm transmits the force generated by the hydraulic motor in to a fixed point. The length of the torque arm determine the force Fr (see chapter "Technical Data" - Table "External forces Fr, Fb for TCA") on motor and driven shaft. The standard torque arm kit состоит из the torque arm, screws, washers and an articulated connection. The articulated connection is a flexible link which allows the motor to follow the rotation of customer shaft within specified limits of misalignment and eccentricity. See chapter "Mounting". Примечание: For installation instructions see Монтаж and maintenance manual for respective Hägglunds motor. (See chapter "Information" - Table "Required and additional documents") Articulated connection rotates with the motor! Risk to life and risk of injury or serious injuries and risk of damage to equipment! (see Figure "Danger zone" below) Make sure the foundation and the customer machine, can withstand the forces from the torque arm. See chapter "Techncial Data" - Figure "External forces Fr, Fb, for TCA" and Table "External forces single ended torque arm valid for a pressure difference of 420 бар static" for single ended torque arms. Danger zone Single ended torque arm without articulated connection, TCA 0050 to 4000 Single ended torque arm without articulated connection, TCA 6000 Single ended torque arm with mounting screws and washers, TCA 0050 to 4000 Single ended torque arm with mounting screws, washers and articulated connection, TCA 6000 Standard, single ended torque arm with mounting screws, washers and articulated connection, TCA 0050 to 4000 1 Mounting screws and washers 2 Torque arm 3 Articulated connection Код типа ln order to identify Hägglunds equipment exactly, the following ordering code is used. These ordering codes should be stated in full in all correspondence e.g. when ordering spare parts. 01 02 03 04 05 06 TC A 01 Torque arm (see chapter "Product Описание") TC 02 Тип A For motor frame size 03 CA 50 0050 CA 70 0070 CA 100 0100 CA 140, CA 210, CBP 140 0210 CB 280, CB 400, CBP 280, CBP 400 F 0400 CB 560, CB 840, CBP 400 C, CBP 560, CBP 840 0840 CB 1120 1120 CBM 2000 2000 CBM 3000/4000 4000 CBM 5000/6000 6000 Attachment 4) 04 Without attachment (see chapter "Product Описание" - Figure "Single ended torque
