Description All-purpose high pressure pump with through drive Size 22 … 500 Nominal pressure up to 400 bar Maximum pressure up to 450 bar Open circuit Features Through drive for mounting of further pumps up to same nominal size Low operating noise Very long service life at high pressures Excellent suction characteristics Working ports SAE flange High total efficiency Swashplate design Technical data Table of values Size 22 28 71 125 180 250 500 250 500 Version Standard High speed Displacement geometric, per revolution Vg cm³ 22 28 71 125 180 250 500 250 500 Nominal pressure pnom bar 400 400 350 350 350 350 350 350 350 Maximum pressure pmax bar 450 450 400 400 450 400 400 400 400 Maximum speed 1) nnom rpm 3600 3000 2200 1800 1800 1500 1320 1900 1500 Flow at nnom qV l/min 79 84 156 225 324 375 660 475 750 Power at nnom and pnom P kW 53 56 91 131 189 219 385 277 438 Torque at pnom M Nm 140 178 396 696 1003 1393 2785 1393 2785 Weight (approx.) m kg 13.5 13.5 34 61 76 120 220 120 220 1) The values are applicable: – at an abs. pressure pabs = 1 bar at the suction port S – for the optimum viscosity range of vopt = 36 to 16 mm2/s - with hydraulic fluid on the basis of mineral oils Downloads 轴向柱塞定量泵 A4FO Data Sheet | RC91455 | 2015-03-01 | Chinese | PDF | 2.9MB Product Groups: Fixed pumps, Fixed pumps Fixed pump A4FO Axial piston fixed pump A4FO Data Sheet | RE91455 | 2015-03-01 | English | PDF | 2.6MB Product Groups: Fixed pumps, Fixed pumps Size 22 to 500 Axialkolben-Konstantpumpe A4FO Data Sheet | RD91455 | 2015-03-01 | German | PDF | 421k Product Groups: Fixed pumps, Fixed pumps Nenngröße 22 bis 500 Axial Piston Fixed Pump A4FO Manual | RE91455-01-B | 2011-06-01 | English | PDF | 2MB Product Groups: Pumps, Fixed pumps Axialkolben-Konstantpumpe A4FO Manual | RD91455-01-B | 2011-06-01 | German | PDF | 2MB Product Groups: Pumps, Fixed pumps
