Шариковый Передача Блоки С solid Сталь Корпус, polymer wiper Уплотнение и Крышка KUM-....-BL-AB-SA

Description With solid steel housing and cover For very high loads and coarse dirt With wiper Cover and housing galvanized Balls made from antifriction bearing steel 1.3505 Technical data Technical data Size 90 C N 25000 C0 N 70000 vmax 1) m/s 2 m kg 11.2 Operating conditions Size 90 Admissible operating temperature (min ... max) 2) -30 °C ... +100 °C 1) In case of prolonged periods of use at speeds above 1 m/s, an increase in temperature and reduction in service life needs to be reckoned with depending on the load. 2) At temperatures above 100 °C, only bright metal load balls without a felt seal should be used. Make allowance for reduction in load capacity. Use high-temperature lubricant! Follow the manufacturer’s instructions! The existing lubricant oil may have to be washed out. At temperatures above 100 °C, only bright metal ball transfer units without a felt seal should be used. Note the reduction in load capacity! Use high-temperature lubricant! Follow the manufacturer’s instructions! The existing lubricant oil may have to be washed out. Temperature factor Temperature (°C) Temperature factor ft 125 0,9 150 0,8 175 0,7 200 0,5 The load capacity must be multiplied by the temperature factor. Legend Symbol Description Unit Picture C Dynamic load capacity N C0 Static load capacity N vmax​ Conveying speed m/s m Mass kg Technical data Fields of application Applications General-purpose machines Feed tables for sheet-metal working machines Fixtures for press brakes Feed devices for machining centers Drilling tables and motor-driven supporting tables Assembly aids in the manufacture of large engines and motors Construction of special-purpose machines Aerospace industry Beverages and stone-processing industries Not suitable for use under water Conveyor systems Ball transfer tables, turntables and switches for sorting and distribution systems Crossover sections of continuous conveyors Baggage sorting systems at airports Transport of steel tubes and pipes Lifting platforms Dimensions Dimensions Size dw D Tolerance for D h h1 H Tolerance for H G mm mm mm mm mm mm mm 90 90 145 ± 0.08 25 30 115 ± 0.2 Rp 1/8 Installation dimensions Size S Tk W mm mm 90 9 125 6 x 60° Mounting Lube port in the cover and housing Ball Transfer Unit Installation Examples Certification Directives and standards Safety Instructions Notes Ordering codes Ordering code Size Part number Short product name Buy 90 R053311110 KUM-B90-BL-AB-SA Downloads Ball Transfer Units Catalog | R999000498 | 2016-07-01 | English | PDF | 4.8MB Product Groups: Ball transfer units and tolerance rings
