Description Open-type format for self-supporting installation Long lengths possible thanks to shaft support rail High feed system power Rexroth precision ball screw assembly in rolled design tolerance grade T7 in accordance with DIN 69051 with backlash-free cylindrical nut High traversing speed due to large leads Features Inexpensive maintenance thanks to the one-point lubrication (grease lubrication) on two sides of the guide system With bellows cover Simple motor mounting using centering recess and thread Wide range of accessories available Product description Linear motion slides are an inexpensive solution for a wide variety of applications. Linear motion slide guides consist of linear bushings that ensure quiet travel and a long service life. Linear motion slides with an open design are fastened to the mounting base using shaft support rails. Structural design Fixed-bearing end block Shaft support rail Ball screw assembly with backlash-free, cylindrical single nut Carriage with four super linear bushings (size 8-65 with standard linear bushings) Polyurethane protective bellows Floating bearing end block Attachment parts Motor with control units Switch (inductive and mechanical) Socket and plug Cable duct made of aluminum profile Technical data Maximum values for each size Size SOK-085 SOK-100 SOK-130 SOK-160 SOK-180 SOK-230 SOK-280 C N 2850 3440 6100 11950 14520 24950 36380 Cbs N 2200 3800 12300 15700 31700 Cfb N 5280 13400 17000 26000 Mt Nm 25 39 134 320 425 928 1687 ML Nm 27 41 141 339 447 1057 1853 Mx max Nm 10 16 49 127 177 350 644 My max Nm 11 17 52 134 186 399 708 Mz max Nm 11 17 52 134 186 399 708 Fy max N 1020 1260 2140 4500 5760 8960 13240 Fz max N 1020 1260 2140 4500 5760 8960 13240 Lmax mm 1000 1500 2500 3000 4000 amax m/s² 27 vmax m/s 0.25 1 1.24 1.26 1.6 Maximum values depends on the selected configuration. Legend Symbol Description Unit C Dynamic load capacity, linear guide N Cbs Dynamic load capacity, ball screw drive N Cfb Dynamic load capacity, fixed bearing N Mt Dynamic torsional moment load capacity Nm ML Dynamic longitudinal moment load capacity Nm Mx max Maximum admissible torsional moment around the x-axis Nm My max Maximum admissible torsional moment around the y-axis Nm Mz max Maximum admissible torsional moment around the z-axis Nm Fy max Maximum dynamic load in y-direction N Fz max Maximum dynamic load in z-direction N Lmax Maximum length mm amax Maximum acceleration travel m/s2 vmax Maximum permissible speed m/s Mounting Switching system overview 1 Socket and plug 2 Mechanical switch (with attachments) 3 Proximity switch (with attachments) 4 Switching cam 5 Profiled support 6 Mounting bracket 7 Cable duct (aluminum alloy) Switch mounting arrangements The switching position indicates the position of the carriage center (TM) after moving. The zero point is at L / 2. Maximum switching position = 0.5 · travel path max. – excess travel For safe operation of the Linear Motion Slide, the excess travel must be greater than
