Pneumatic Зажимной Блоки MK R1619 .42 6.

Description High axial holding forces with short format Dynamic and static stabilization in the axial direction Simple mechanical gripping principle in LCP and LCPS with good price/performance ratio Easy mounting Clamps with pressure (pneumatic) The clamping profiles are pressed by compressed air via a dual acting gate valve gear mechanism. Features Chemically nickel-plated steel housing High axial and horizontal rigidity Exact positioning, high dynamics, powerful drive and long service life through the use of high-precision linear screw drives Continuously adjustable pressure from 4 - 8 bar Decompression with spring force. A pre-tensioned return spring allows for short decompression cycles. 5 million clamping cycles (B10d value) Product description Functional principle Clamping with air pressure or spring force Clamping profiles are pressed to the web surfaces of the Ball Guide Rail. Decompression with air pressure or spring force The clamping profiles are held apart. Free movement is possible Technical data General technical data Size 15 20 25 30 35 45 55 65 20/40 25/70 35/90 Spring energy holding force with standard air port 1) N 650 1000 1200 1750 2000 2250 650 1200 2000 Air consumption (normal liter) standard air port dm³/stroke 0.111 0.019 0.021 0.031 0.041 0.019 0.021 0.031 Max. pneumatic operating pressure bar 8 Mass kg 0.25 0.36 0.45 0.72 0.88 1.7 1.95 2.68 0.37 0.62 0.88 Operating conditions Size 15 20 25 30 35 45 55 65 20/40 25/70 35/90 Permissible ambient temperature (min ... max) ​0 °C ... +70 °C 1) Holding force at 6 bar. The inspection is done in a mounted state with a lubricated layer (ISO-VG 68). Symbols/Circuit diagrams Circuit type1) for standard air port 1) Holding force at 6 bar. The inspection is done in a mounted state with a lubricated layer (ISO-VG 68). a) Air port*) M5 on both sides for release pressure b) Connection*) M5 on both sides for air filter *) Only one connection needed All connections sealed upon delivery. 1 Air port 2 Working connection 3 Venting Fields of application Pneumatic clamping of machine axes Table crossbars in the timber industry Positioning of lifting gear Dimensions a) Air connection*) M5 on two sides for release pressure b) Connection*) M5 on two sides for air filter c) Adjusting screw on two sides d) Spacer plate (accessory) for MK e) Air filter: connection M5 (possible on two sides) *) Only one connection needed. All connections sealed upon delivery. Dimensions Size 15 20 25 30 35 45 55 65 20/40 25/70 35/90 A mm 55 66 75 90 100 120 128 138 80 120 156 B mm 39 35 39 49 39 35 42 E1 mm 15 20 22 24 26 30 20 50 60 E2 mm 15 20 22 24 26 30 20 E3 mm 15.5 9 5 8.5 7.5 11.5 9.5 15.5 5 9.5 F1 mm 5.6 4.5 7 8.5 11 14.5 17 14.5 5 7 11.5 F2 mm 34 17.3 17.5 15 14.5 19.5 4.5 17.5 18 F3 mm 16.1 6 7 10.3 12 14.5 17 14.5 5 9 14 F4 mm 34 34.5 30 24.5 29.5 31 30 36.5 H mm 24 30 36 42 48 60 70 90 27 35 50 H1 1) mm 20.8 27 32.5 38.5 44 52 57 73.5 23.5 32.5 45.5 N3 mm 4.5 6 8 9 10 15 20 4.5 8 10 S2 M4 M6 M8 M10 M4 M6 M1
