Описание High pressure pump for applications in commercial vehicles Size 23 … 107 Nominal pressure 350 bar Maximum pressure 400 bar Open circuit Features Flange and shaft designed for direct mounting on the power take-off of commercial vehicles Optimized weight by cast aluminum housing No drain line required Low operating noise Simple adjustment of rotatonal direction Excellent suction characteristics High total efficiency Long service life Bent-axis design Type code 01 02 03 04 05 06 07 08 09 10 11 A17F O / 10 N L W K0 E8 1 ‒ Axial piston unit 01 Bent-axis design, fixed, for commercial vehicles (truck) A17F Operating mode 02 Pump, open circuit O Nominal size 03 Geometric displacement, see tables of values 023 032 045 063 080 107 Series 04 Series 1, index 0 10 Design of ports and fastening threads 05 Metric, port threads with profiled sealing ring according to DIN 3852 N Direction of rotation1) 06 Viewed on drive shaft, counter-clockwise L Seal material 07 FKM (fluor-caoutchouc) including the 2 shaft seal rings in FKM W Mounting flange 08 Special flange ISO 7653-1985 (for trucks) K0 Drive shaft 09 Splined shaft similar to DIN ISO 14 (for trucks) E8 Working port 10 Threaded ports A and S at rear 1 Standard/ special version 11 Standard version 0 Special version S 1) For changing the direction of rotation: see Technical data, chapter "Direction of rotation" Technical data Table of values Size 23 32 45 63 80 107 Displacement geometric, per revolution Vg cm³ 22.9 32 45.6 63 80.4 106.7 Nominal pressure pnom bar 350 350 350 350 350 350 Maximum pressure pmax bar 400 400 400 400 400 400 Maximum speed nnom 1) rpm 3050 2750 2650 2200 2150 2000 nmax 2) rpm 4300 3900 3800 3200 3100 2800 Flow at nnom qV l/min 70 88 121 139 173 213 Power at nnom and pnom P kW 41 51 71 81 101 124 Torque at pnom M Nm 127 178 254 351 448 594 Rotary stiffness c kNm/rad 2.56 3.12 4.18 6.25 8.73 11.2 Moment of inertia for rotary group JTW kg·m² 012 012 03 042 072 0.0116 Maximum angular acceleration ɑ rad/s² 6500 6500 14600 7500 6000 4500 Case volume V l 0.25 0.29 0.4 0.5 0.6 0.75 Mass moment MG Nm 4.7 4.7 8.6 9.9 15.3 20 Weight (approx.) m kg 5.9 5.9 8.4 9.3 12.3 15 1) The values are applicable: – at an abs. pressure pabs = 1 bar at the suction port S – for the optimum viscosity range of vopt = 36 to 16 mm2/s - with hydraulic fluid on the basis of mineral oils 2) Maximum speed (limiting speed) with increased inlet pressure pabs at suction port S , see the following diagram. Maximum speed Note The values in the table are theoretical values, without consideration of efficiencies and tolerances. The values are rounded. Exceeding the maximum or falling below the minimum permissible values can lead to a loss of function, a reduction in operational service life or total destruction of the axial piston unit. Other permissible limit values, such as speed variation, reduced angular acceleration as a function of the frequency and the permissible angular acceleration at start (lower than the
